CNB EN733 CENTRIFUGAL PUMP
·Absorb water axially and discharge water radially.
·The water inlet and outlet comply with the provisions of EN733.
·The fanges refer to the provisions of UNI2236 and DIN2532.
·Back pull-out design: (The impeller and motor can be removed when the pump body is connected to the pipeline.)
CNB STRUCTURAL CHARACTERISTICS
·The fow rate can reach: 0 - 210 m³/h.
·The head can reach: 9 - 95 m.
·The temperature of the pumped liquid: standard -10 °C - +85 °C.
·The maximum working pressure: 12 bar.
·The maximum altitude: 1000 m.
·When obsered at the water inlet of the pump, it rotates counterclockwise.
